MS3816 - MORTISER WITH 370 W /220V /50 Hz / 1 PH MOTOR
1.Cast iron machine with moving table and work clamp
2.Drill bit held by 13mm drill chuck on motor shaft.
3.Square chisel held by clamping bolt in cast iron head.
4.Complete work head strokes up and down by hand lever.
5.Cast iron work table moves sideways by central lever, and adjusts in a
nd out by knurled knob.
6.Screw type work clamp locks timber onto work table.
7.Depth stops can be pre-set on head rise
1.Cast iron machine with moving table and work clamp
2.Drill bit held by 13mm drill chuck on motor shaft.
3.Square chisel held by clamping bolt in cast iron head.
4.Complete work head strokes up and down by hand lever.
5.Cast iron work table moves sideways by central lever, and adjusts in a
nd out by knurled knob.
6.Screw type work clamp locks timber onto work table.
7.Depth stops can be pre-set on head rise
